Q-Max AC 200 Extractor (1120 m3/h) Can-Fan

Extractor Q-Max AC 200 (1120 M3/h) Can-Fan

The Extractor Q-Max AC 200 (1120 M3/h) Can-Fan integrates an inline mixed-flow fan inside a metal body lined with acoustic foam, achieving sound attenuation without sacrificing performance. The 3D rotor–stator architecture straightens the airflow and reduces turbulence, so the available pressure remains stable even when the circuit includes carbon filters, bends, or long duct runs.

The built-in controller allows you to choose between three speeds to adapt the airflow to each stage of cultivation. Key specifications for project sizing: nominal airflow 1120 m³/h, power 110 W, current 0.5 A (Imax 0.6), supply 230 V, max. reference sound level 68 dB, total length 676 mm, and flange of ≈199–200 mm. The motor features TAI protection and Class F insulation, designed to offer safety and reliability in demanding environments (TA/Tm 40 °C).

The unit is quickly installed on the ceiling or wall using clamps and anti-vibration straps, ready to move large volumes of air with contained consumption.

Available at Hydroponics Blanes, Grow Shop in Spain with technical advice, discreet shipping, and a wide catalog of cannabis cultivation accessories and cheap indoor grow tents from a true trusted Grow Shop.

Indoor Cultivation Extractor Q-Max AC 200 (1120 M3/h) Can-Fan

Well-sized extraction stabilizes temperature, humidity, and CO₂ levels. Extractor Q-Max AC 200 (1120 M3/h) Can-Fan stands out for high airflow with low noise, ideal for medium tents and compact rooms where silence and static pressure make the difference when passing through filters and silencers.

What is the Extractor Q-Max AC 200 (1120 M3/h) Can-Fan for?

• Constant air renewal: effective removal of heat and humidity.
• Odor control: optimal operation together with 200 mm carbon filters.
• Available pressure: stable performance against losses from bends and long runs.
• Quick airflow adjustment: 3 speeds to adapt flow to each phase or season.

Indoor cultivation accessory Extractor Q-Max AC 200 (1120 M3/h) Can-Fan

Among the essential cannabis cultivation accessories, this silenced reference combines energy efficiency, easy installation, and full compatibility with flexible or rigid 200 mm ducts, grilles, reducers, and environmental controllers. The internal acoustic foam dampens humming and minimizes the system's aerodynamic noise.

What is the Extractor Q-Max AC 200 (1120 M3/h) Can-Fan used for?

Recommended use as the main extractor in medium-sized tents (e.g., 120×120, 120×240 cm, always according to lighting power and duct length), as an adjustable intake in rooms requiring controlled fresh air supply, and in drying rooms where continuous flow prevents humidity spikes and improves process uniformity.

How to use Extractor Q-Max AC 200 (1120 M3/h) Can-Fan

1. Calculate need: room volume (m³) × air changes/hour (30–60 as reference) and add losses from filter and bends.
2. Place the extractor in a high area to evacuate accumulated hot air; plan a short duct run with few direction changes.
3. Connect to 200 mm duct and equivalent carbon filter; seal joints with aluminum tape and secure with clamps.
4. Hang with straps and anti-vibration plugs to reduce structural transmission; check fastenings after the first hours of operation.
5. Select one of the 3 speeds on the integrated controller, adjusting the flow to thermal load and schedule.
6. Check draft with an anemometer or manual test; inspect for possible leaks at joints and retighten clamps if necessary.
7. Schedule maintenance: clean pre-filters and check ducts to maintain 1120 m³/h and contained noise level.

Advantages of using Extractor Q-Max AC 200 (1120 M3/h) Can-Fan

• Integrated soundproofing with acoustic foam in metal housing.
• 3D rotor–stator that straightens the flow and improves pressure in the duct.
• 3 speeds with built-in controller for immediate adjustment.
• Efficiency: airflow 1120 m³/h with 110 W and 0.5 A nominal.
• Safety: motor protection TAI and insulation Class F.

Where to buy an Extractor Q-Max AC 200 (1120 M3/h) Can-Fan online?

Available at Hydroponics Blanes, with expert service from a trusted Grow Shop, discreet shipping, and everything you need for Indoor cultivation: controllers, ducts, filters, and cheap indoor grow tents. Secure purchase at Grow Shop in Spain with advice to size ventilation according to LED power and system layout.

Indicative technical data sheet: Airflow 1120 m³/h • Outlet ≈200 mm • Length 676 mm • Power 110 W • Current 0.5 A (Imax 0.6) • Supply 230 V • 3 speeds • Max. sound level 68 dB • Protection TAI • Insulation Class F • TA/Tm 40 °C.

For installations that require real silence, constant pressure, and immediate airflow adjustment, Extractor Q-Max AC 200 (1120 M3/h) Can-Fan becomes a key ally: silenced design, efficient rotor–stator, and integrated controller. With the support of Hydroponics Blanes and discreet shipping, completing Indoor cultivation systems is quick, safe, and compatible with cheap indoor grow tents and other accessories.
